Black Brant IV 1/10 scale rocket kit

LISTING < PREV NEXT >

Black Brant IV 1/10 scale rocket kit


$61.45
In Stock. Ships today

  • Uses D, E, F Estes and Aerotech Motors
  • 22 Laser Cut Parts
  • Thick, white tubes
  • Plastic nose cone and transition
  • Vinyl and water-slide decals included
  • Ejection Baffle (no wadding required)
  • Comes with 18" Plastic Parachute
  • Over 43" Tall
  • Requires 3/16" Launch Rod
  • Intermediate Assembly Skills Required

Recommended Engines:

D12-5, E12-6
E15-7, E20-7, E30-7, F44-8
E18-7, E28-7, F24-7

Specifications

  • Length: 43.9" (111 cm)
  • Diameter: 1.72" (43.7 mm)
  • Weight: 5.54 oz. (157 g)
  • Motor Mount: 24 mm.
  • Recovery System: 18" Plastic Parachute, Ejection Baffle
  • Projected Max Altitude: 1650 ft. (500 m)

Description

Original Black Brant IV was a two-stage rocket consisting of Black Brant V first stage with the Black Brant III second stage and was used by Canadian Space Agency and NASA. This kit is a single-stage model of Black Brant IV

Construction Video*

* This video does not substitute the instructions provided with rocket. The videos below provided by an independent builder and some steps are not exactly as per instructions.

Everything in this section is needed to build and fly this rocketPriceAdd to Cart
Complete Launch System by Estes$50.20Buy
3/16" 2-Piece Maxi-Rod$19.00Buy
CA C-Bond Thin$7.50Buy
DuraPro Carpenters Glue. 236ml$7.50Buy
Hobby Knife with Safety Cap$4.20Buy
4 Sanding sheets Grit 150 to 600$3.10Buy
Tamiya Pure White Spray Paint. TS26$11.00Buy
Tamiya Mica Red Spray Paint. TS39$11.00Out Of Stock
D12-5 model rocket engine. 2 pack$17.20Buy
4 pack of 1.5 v ProCell AA batteries$4.95Buy
Recommended MotorsPriceAdd to Cart
D12-5 model rocket engine. 2 pack$17.20Buy
E12-6 Mid-Power rocket engines. 3 Pack$33.65Buy
E20-7W model rocket engines. 2 Pack$41.25Out Of Stock
E30-7T model rocket engines. 2 Pack$41.25Buy
F44-8W 24mm rocket motor 2 pack. 41.5Ns/1 sec$47.50Buy
24/40 ReloadsPriceAdd to Cart
E18-7W 24/40 Reload Kit. 3 Pack$46.75Buy
E28-7T 24/40 Reload Kit. 3 Pack$46.75Buy
F24-7W 24/40 Reload Kit. 3 Pack$53.00Buy



  • Manufactured by: Rocketarium
