• Military-Scale Rocket
• Uses D, E Estes or D, E, F Aerotech Motors
• Comes with Ejection Baffle (no wadding required)
• Includes laser-cut centering rings and fins, plastic nose and tail-cone, 15" plastic parachute kit.
• There are two sets of fins line up on the rocket.
• Over 34" Tall
• Intermediate Assembly Skills Required

Recommended Engines:

D12-5 (600 ft), E12-6 (1000 ft), E15-7 (1450 ft), E20-7 (1300 ft), F30-6 (1550 ft), F32-6 (1850 ft), F44-8 (1450 ft)

Aerotech® RMS 24/40: D15-4 (700 ft), E18-7 (1400 ft), E28-7 (1450 ft), F12-5 (1550 ft), F24-7 (1650 ft),F39-6 (1650 ft)

Pro24®: 24-E22-6 (950 ft), 26-E31-6 (1100 ft)

Specifications

• Length: 34.2" (87 cm)
• Diameter: 1.64" (42 mm)
• Weight: 3.5 oz. (100 g)
• Motor Mount: 24 mm
• Recovery System: Parachute

Description

This is a scale version of the popular Advanced Medium-Range Air-to-Air Missile. The actual missile is powered by solid-propellant rocket motors. The rocket kit flies on motors ranging from a D12 to an F44.

There are lots of small pieces and decals. Cutting out and handling the small decals can take time.

Construction Video*

* This video does not substitute the instructions provided with rocket. The videos below provided by an independent builder and some steps are not exactly as per instructions.

• Amraam assembly

Requires

• Assembly
• Motor, Igniter
• Basic Launch System or Mid Power Launch System to launch with composite motors
• Maxi Launch Rod
• Carpenter's glue
• Fine Sand Paper
• Utility or Hobby Knife
• Masking Tape (optional)
• Primer (optional) & Paint
