Skill Level: 3
Recommended Age: 14+
The Alamo is an Air-to-Air missile which targets just about anything that flies, including helicopters, drones and even other missiles! NATO has given this AAM missile the name AA-10 Alamo, it is also known as the Vympel R-27.
This highly-detailed Alamo military scale kit is excellent for small launch sites. It is a large and heavy model rocket. Ignite those slow launches that everyone can enjoy!
Three (3) sets of fins and a boat tail give this scale model rocket kit lots of personality.
Pick up this scale model of this medium-range missile today for some serious modeling fun.
Challenges
The Alamo military scale rocket kit has three sets of laser-cut fins, for a total of twelve fins. Epoxy is required and CA glue is also recommended to assemble this kit.
Parts
The AA-10 Alamo comes compete with laser-cut centering rings, fins, Decals, Ejection Baffle, plastic Nose Cone and Tailcone and 15" Plastic Parachute Kit.
Length: 30" (76 cm)
Diameter: 1.64 in. (76 mm)
Estimated Weight:8.5 oz. (210 g)
Recommended motors:
Recommended Single Use Engines (apogee): D12-5(480 ft), E12-6(880 ft), E20-7(900 ft), E15-7(1060 ft), F32-6 (1260 ft)
Aerotech® RMS 24/40 (apogee): D15-4(530 ft), E18-7(980 ft), F24-7(1150 ft)
Pro24® (apogee): 24-E22-6(650 ft), 26-E31-6(700 ft)
Construction Video*
* This video does not substitute the instructions provided with rocket. The videos below provided by an independent builder and some steps are not exactly as per instructions.
Requires
